LNB Vast Dual Output

$ 32.50 inc GST

The Vast LNB – Dual Output is a high-performance dual output KU band PLL LNB designed for VAST satellite TV, Fox and more. Featuring a 10.7GHz local oscillator and PLL technology, it ensures optimal performance with low current operation. This LNB offers high gain with low noise and a flat output response across a 54MHz bandwidth, making it an excellent choice for reliable satellite TV reception.



Category: SKU: DUALOUTLNB

Description

For use with your satellite dish, this is a dual output, dual polarity (horizontal/vertical) LNBF that receives the signal for Vast TV and Fox.

The LNB

High Gain Dual Polarity 10.7GHz LO Ku Band LNBs. Higher gain and new ultra-compact design.

  • Outputs 2
  • Input Frequency Range 11.7GHz to 12.75GHz
  • Output Frequency Range 1000MHz to 2050MHz L.O. Frequency 10.7GHz L.O.
  • Accuracy Initial Accuracy (@ 25°C): ±1MHz L.O.
  • Temperature Drift -30oC to +60oC: ±1.5MHz L.O.
  • Phase Noise @ IKHz Offset: -60dBc/Hz @ I0KHz Offset: -80dBc/Hz @ I00KHz Offset: -95dBc/Hz Noise Figure @ 25°C: 0.7dB (typ.)
  • Conversion Gain @ 25°C: 60dB to 72dB
  • Image Rejection 40dB min.
  • Output VSWR 2.0:1 Cross-Pole Isolation 20dB min.
  • Supply Voltage Vertical Polarisation: 10.5V to 14.5V Horizontal Polarisation: 15.5V to 21.0V Current consumption 100mA max. 115mA max.
  • Load Impedance 75Ohm Reflector Type Offset F/D Ratio 0.6 Feedarm
  • Mount 40mm Ø
  • Storage Temperature -30°C to +60°C
  • Output Connector 75Ω F type
  • Gain Flatness 6dBpp (typ.) / entire band 1.5dBpp (typ.) / 27MHz L.O.
  • Spurious -30dBm max.

Additional information

Weight6 kg
Dimensions80 × 15 × 80 cm
